GIGABYTE B650M H AM5 Micro-ATX Motherboard

GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
GIGABYTE B650M H AM5 Micro-ATX Motherboard
Price : 12,999 Tk
Regular Price: 15,180 Tk
Status: In Stock

Key Features

  • Model: B650M H
  • Supported CPU: Ryzen 9000 / 8000 / 7000 Series Processors for Socket AM5
  • Supported Memory: 2 x DDR5 6400(OC) Max. 96GB
  • Graphics Output: 2 x DisplayPort, 1 x HDMI port
  • Features: 1 x DisplayPort, 1 x HDMI
Based on 0 reviews. - Write a review
12,999 Tk
Ex Tax: 12,999 Tk
Add to Cart
Buy Now Question
Add to Wish List Compare this Product


বিঃদ্রঃ অস্থিতিশীল বাজার পরিস্থিতির কারণে পণ্য অর্ডার করার পূর্বে আমাদের হট লাইনে যোগাযোগ করুন।

Basic Information
Supported CPU AMD Socket AM5, support for: AMD Ryzen 7000 / Ryzen 8000 / Ryzen 9000 Series Processors
Chipset AMD B650
BIOS 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 23.0cm x 22.5cm
Audio Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
Expansion Slots
PCI 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: - AMD Ryzen 7000 Series Processors support PCIe 4.0 x16 mode - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1(PCIEX1)
Memory
RAM Type DDR5
Total RAM Slot 2 x DIMM
Supported Memory 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
Max RAM Capacity supporting up to 96 GB (48 GB single DIMM capacity) of system memory
Graphics
Graphics supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version. supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support for native HDMI 2.1 TMDS compatible ports.
Connector & Ports
HDMI Port 1x HDMI
Display Port (s) 1 x DisplayPorts
USB (s) CPU: - 2 x USB 3.2 Gen 1 ports on the back panel - 1 x USB 2.0/1.1 port on the back panel Chipset: - 2 x USB 3.2 Gen 1 ports available through the internal USB header - 7 x USB 2.0/1.1 ports (3 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s) Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Supported Storage 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs: - AMD Ryzen 7000 Series Processors support PCIe 4.0 x4/x2 SSDs - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 4 x SATA 6Gb/s connectors
RAID RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Audio 3 x audio jacks
Internal I/O Ports 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Clear CMOS jumper Back Panel Connectors 4 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 1 x Q-Flash Plus button 2 x USB 3.2 Gen 1 ports 1 x DisplayPort
TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
Other Features
Special Features Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus
Bundled Software Norton Internet Security (OEM version) LAN bandwidth management software
Warranty
Manufacturing Warranty 3 years

GIGABYTE B650M H AM5 Micro-ATX Motherboard

The GIGABYTE B650M H AM5 Micro-ATX Motherboard is a compact and feature-rich platform designed to support AMD's latest Ryzen 7000, 8000, and 9000 series processors, utilizing the AM5 socket. This motherboard offers a robust power delivery system with a 5+2+2 phases digital VRM solution, ensuring stable and efficient performance, especially under demanding conditions. It supports Dual Channel DDR5 memory through 2 SMD DIMMs, compatible with both AMD EXPO and Intel XMP memory modules, allowing users to easily overclock and optimize their system's memory performance. The B650M H provides a PCIe 4.0 x4 M.2 connector, offering high-speed storage capabilities that significantly enhance system responsiveness. The EZ-Latch feature on the PCIe x16 slot simplifies the installation and removal of graphics cards with a quick-release design, making hardware upgrades and maintenance straightforward. Equipped with Gigabit Ethernet LAN, the motherboard ensures reliable and fast network connectivity, ideal for gaming and data-intensive tasks. The motherboard also includes versatile connectivity options with DisplayPort and HDMI outputs, supporting various display setups and multi-monitor configurations. Its Smart Fan 6 technology provides multiple temperature sensors and hybrid fan headers, including the capability to stop fans completely when not needed, ensuring optimal cooling and minimal noise. Additionally, the Q-Flash Plus feature allows for easy BIOS updates without the need to install a CPU, memory, or graphics card, simplifying system maintenance and upgrades. The GIGABYTE B650M H AM5 Micro-ATX motherboard offers a well-rounded package for users seeking a reliable and efficient system build, whether for gaming or professional use.

GIGABYTE B650M H AM5 Micro-ATX Motherboard from best Computer Shop in Bangladesh

You can get the original GIGABYTE B650M H AM5 Micro-ATX Motherboard from best Computer Shop in Bangladesh. We have a large collection of the latest GIGABYTE AMD Motherboard to purchase for your Processor. Order Online Or Visit your Nearest Seegate Technology Shop to get yours at the lowest price.

What is the price of GIGABYTE B650M H AM5 Micro-ATX Motherboard in Bangladesh?

The latest price of GIGABYTE B650M H AM5 Micro-ATX Motherboard in Bangladesh is 13,800Tk. You can buy the GIGABYTE B650M H AM5 Micro-ATX Motherboard at the best price from our website or visit any of our showrooms.
